Schottky Diode Selection Guide: High-Efficiency Rectification from DO-41 to TO-247AC

In modern power electronics, Schottky barrier diodes stand out for their ultra-low forward voltage drop (VF) and fast switching speeds—making them the go-to choice for efficient rectification, reverse polarity protection, and high-frequency power conversion. Compared to standard PN-junction diodes, Schottky diodes reduce conduction losses and heat generation, especially in high-current and high-frequency applications.

This blog dives deep into a curated lineup of popular Schottky diodes—from the compact axial 1N5819 (DO-41) and SR3100 series (DO-27), to mid-power dual-chip SR1060/SR10100, and finally the heavy-duty MBR series in TO-220AC and TO-247AC packages. Whether you’re designing a phone charger or a 10 kW solar inverter, this guide helps you pick the right part fast.

1. Low-Power Axial Packages: 1N5819 & SR3xxx Series (1A–3A)



1N5819 (DO-41)

  • Rating: 1A / 40V
  • VF: ~0.55V @ 1A
  • Package: DO-41 (axial, φ2.7 mm)
  • Best for: Low-voltage DC-DC buck converters, battery chargers, polarity protection
  • Pros: Dirt-cheap, widely available
  • Cons: Limited heat dissipation—use copper pours or small heatsinks

SR3100 / SR3150 / SR3200 (DO-27)

ModelCurrentVoltageVF (typ.)Package
SR31003A100V0.85VDO-27
SR31503A150V0.92VDO-27
SR32003A200V0.95VDO-27
  • Package Advantage: DO-27 (φ3.6 mm) supports higher current than DO-41
  • Applications: SMPS output rectification (<100 kHz), solar MPPT controllers, EV charging (low-voltage side)
  • Selection Tip:
    • Use 100V for 48V systems
    • Go 150V/200V for 60V–120V industrial supplies to survive voltage spikes

2. Mid-Power Dual-Chip Solutions: SR1060 / SR10100 (DO-27)

ModelCurrentVoltageVF (typ.)Package
SR106010A60V0.70VDO-27
SR1010010A100V0.85VDO-27
  • Internal Design: Two 5A dies in parallel
  • Thermal Design: Requires >100 mm² copper or small clip-on heatsink; keep TJ < 125°C
  • Use Cases: 48V telecom rectifiers, UPS output stages, power tool controllers

3. High-Power TO-220AC Single-Chip: MBR10100 / MBR20100 / MBR20150

ModelCurrentVoltageVF (typ.)Package
MBR1010010A100V0.80VTO-220AC
MBR2010020A100V0.80VTO-220AC
MBR2015020A150V0.90VTO-220AC
  • Key Features: High current density, easy screw-mount heatsinking
  • Thermal ResistanceRθJA ≈ 2.5°C/W (drops below 1°C/W with heatsink)
  • Applications:
    • 100V: Industrial inverters, servo drives
    • 150V: Grid-tied PV inverter output rectification

4. Ultra-High-Power TO-247AC Dual-Chip (Common Cathode): MBR30xxx ~ MBR60xxx Series

The TO-247AC package with dual-chip common-cathode configuration delivers 30A–60A per device—ideal for mission-critical high-power rectification.

ModelCurrentVoltageVF (typ.)Package
MBR30100PT30A100V0.80VTO-247AC
MBR30200PT30A200V0.95VTO-247AC
MBR4060PT40A60V0.70VTO-247AC
MBR40100PT40A100V0.80VTO-247AC
MBR40150PT40A150V0.90VTO-247AC
MBR6040PT60A40V0.65VTO-247AC
MBR6060PT60A60V0.70VTO-247AC
MBR60200PT60A200V0.95VTO-247AC

40A Series Head-to-Head

ParameterMBR4060PTMBR40100PTMBR40150PT
VRRM60V100V150V
VF @ 20A0.65V0.75V0.85V
IFSM (8.3ms)300A350A350A
RθJC0.8°C/W0.7°C/W0.7°C/W

Application Mapping

Voltage RangeSystem ExampleRecommended Part
40–60VElectric forklifts, ESS BMSMBR6040PT / MBR6060PT
100VServo systems, wind pitchMBR30100PT / MBR40100PT
150–200VPV string combiners, rail auxMBR40150PT / MBR30200PT / MBR60200PT

5. Quick Selection Checklist

  1. Voltage HeadroomVRRM ≥ 1.5 × Vin,peak (include surge margin)
  2. Current Sizing
    • Average: IAVG = Iload × 0.8 (full-wave)
    • Peak: Plan for 5–10× surge
  3. Thermal BudgetPD = VF × IAVGTJ = TA + PD × RθJA → Always use aluminum heatsink + thermal pad for TO-247AC
  4. Paralleling Tips
    • Dual-chip parts are internally matched
    • For multi-device: Match VF within 5%, add current-sharing inductors
  5. Cross-Reference
    • SR series: MIC, TSC, GS
    • MBR series: Onsemi, MCC, Vishay (pin-compatible)

6. Final Thoughts

From the humble 1N5819 at 1A/40V to the beastly MBR60200PT at 60A/200V, Schottky diodes span the full spectrum of power needs. Smart selection boosts efficiency, cuts thermal stress, and optimizes BOM cost and PCB real estate.

Pro Tip: In 48V–100V designs, the MBR4060PT is the sweet spot—lowest VF + excellent thermal performance. For 150V+, step up to MBR40150PT or higher.

Upgrade Path: DO-27 → TO-220AC → TO-247AC Always pair with TVS + NTC for surge protection in schematics.

Need PCB layout tips, thermal simulation files, or cross-reference spreadsheets? Drop a comment below!
